| Coupling Size | ERubber | F-Hub | H-Hub | Bush Size | Bore Size | A | B | C | D | E | F | G | J | Weight (Kgs) | Torque Nom (Nm) | Torque Max (Nm) | RPM Max | Axial | Misalignment Radial | Angular | Bore d | Inertia(gm^2) Bus hed |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
7 |
HRC/O C 70 E |
HRC/O C 70 F |
HRC/O C 70 H |
1008 |
9-25 |
69 |
60 |
20 |
24 |
31 |
25 |
18 |
29 |
1 |
33 |
73 |
7700 |
0.2 |
0.3 |
0.5 |
0.85 |
0.78 |
|
9 |
HRC/O C 90 E |
HRC/O C 90 F |
HRC/O C 90 H |
1108 |
9-28 |
85 |
70 |
19.5 |
23.5 |
32 |
30.5 |
23 |
29 |
1.2 |
84 |
185 |
6300 |
0.5 |
0.3 |
0.5 |
1.15 |
1.08 |
|
11 |
HRC/O C 110 E |
HRC/O C 110 F |
HRC/O C 110 H |
1610 |
14-42 |
112 |
100 |
18.5 |
26.5 |
45 |
45 |
29 |
38 |
4.5 |
168 |
370 |
5000 |
0.6 |
0.3 |
1 |
4 |
3.44 |
|
13 |
HRC/O C 130 E |
HRC/O C 130 F |
HRC/O C 130 H |
1610 |
14-42 |
130 |
105 |
18 |
26.5 |
50 |
54 |
36 |
38 |
5 |
331 |
728 |
4100 |
0.8 |
0.4 |
1 |
7.8 |
8.5 |
|
15 |
HRC/O C 150 E |
HRC/O C 150 F |
HRC/O C 150 H |
2012 |
14-50 |
150 |
115 |
23.5 |
33.5 |
62 |
61 |
40 |
42 |
7 |
630 |
1490 |
3600 |
0.9 |
0.4 |
1.5 |
18.1 |
21.12 |
|
18 |
HRC/O C 180 E |
HRC/O C 180 F |
HRC/O C 180 H |
2517 |
16-65 |
180 |
125 |
34.5 |
46.5 |
77 |
74 |
49 |
48 |
16.5 |
998 |
2300 |
3000 |
1.1 |
0.4 |
1.5 |
43.4 |
48.2 |
|
23 |
HRC/O C 230 E |
HRC/O C 230 F |
HRC/O C 230 H |
3020 |
25-75 |
225 |
155 |
39.5 |
52.5 |
99 |
85.5 |
60 |
55 |
25 |
2100 |
4800 |
2600 |
1.3 |
0.5 |
2 |
120.68 |
140.52 |
|
28 |
HRC/O C 280 E |
HRC/O C 280 F |
HRC/O C 280 H |
3525 |
35-90 |
275 |
206 |
51 |
66.5 |
119 |
105.5 |
75 |
67 |
48 |
3308 |
7000 |
2200 |
1.7 |
0.5 |
2.5 |
446.53 |
547.9 |
